What if the AI graded its own answers before giving them to you?

Normal RAG retrieves docs and answers. That’s it. It doesn’t check if the docs were even relevant. It doesn’t check if the answer is hallucinated. It just fires and forgets.

Self-RAG adds a self-evaluation loop. The LLM grades its own retrieved documents, checks its own answer for hallucinations, and validates whether it actually answered the question. Built as a stateful graph with LangGraph.

1. The LangGraph StateGraph

The entire pipeline is a StateGraph — a directed graph where each node is a function that reads and writes shared state:

from langgraph.graph import END, StateGraph, START

class WorkflowState(TypedDict):
    user_question: str
    answer_draft: str
    retrieved_docs: List[str]
    llm_model: ChatGroq
    retriever: Chroma
    has_hallucination: bool
    is_valid_answer: bool

Every node takes WorkflowState in and returns WorkflowState out. The state flows through the graph, accumulating results at each step. No globals. No side effects.

2. The Knowledge Base — Chroma + Embeddings

Two URLs scraped, chunked, embedded, and stored in a Chroma vector database:

splitter = RecursiveCharacterTextSplitter(chunk_size=250, chunk_overlap=0)
split_docs = splitter.split_documents(flat_docs)

vector_db = Chroma.from_documents(
    documents=split_docs,
    collection_name="custom_rag_store",
    embedding=HuggingFaceEmbeddings(model_name="sentence-transformers/all-mpnet-base-v2"),
)
state["retriever"] = vector_db.as_retriever()

all-mpnet-base-v2 — higher quality embeddings than MiniLM, 768-dimensional. Chunk size 250 with no overlap keeps chunks tight and focused.

3. Grading Retrieved Docs — The “Self” in Self-RAG

After retrieval, every document is graded for relevance by the LLM itself using structured output:

class DocRelevanceScore(BaseModel):
    binary_score: str = Field(description="'yes' if document is relevant, otherwise 'no'")

grader = state["llm_model"].with_structured_output(DocRelevanceScore)

for doc in state["retrieved_docs"]:
    score = evaluation_chain.invoke({"document": doc.page_content, "question": state["user_question"]})
    if score.binary_score.lower() == "yes":
        filtered.append(doc)

with_structured_output forces the LLM to return a Pydantic model — no string parsing, no regex. Binary yes/no only.

4. Conditional Routing — Answer or Stop

After filtering, if no relevant docs remain — the graph routes to END instead of generating:

def should_generate_answer(state: WorkflowState) -> str:
    return "answer" if state["retrieved_docs"] else "stop"

workflow.add_conditional_edges(
    "filter_docs_by_relevance",
    should_generate_answer,
    {"answer": "produce_answer", "stop": END}
)

Clean, explicit branching. No if/else spaghetti — just a routing function that returns a string key.

5. Generate the Answer

A standard RAG prompt pulled from LangChain Hub:

prompt_template = hub.pull("rlm/rag-prompt")
rag_chain = prompt_template | state["llm_model"] | StrOutputParser()
state["answer_draft"] = rag_chain.invoke({
    "context": state["retrieved_docs"],
    "question": state["user_question"]
})

The answer goes into answer_draft — not final yet. It still has to pass two checks.

6. Hallucination Detection

The LLM checks its own answer against the retrieved facts:

class HallucinationScore(BaseModel):
    binary_score: str = Field(description="'yes' if grounded in facts, otherwise 'no'")

result = chain.invoke({
    "documents": state["retrieved_docs"],
    "generation": state["answer_draft"]
})
state["has_hallucination"] = (result.binary_score.lower() != "yes")

has_hallucination is True when the answer is NOT grounded. Flagged in the final output.

7. Answer Validation

One final check — does the answer actually address the question?

class AnswerValidityScore(BaseModel):
    binary_score: str = Field(description="'yes' if answer addresses the question, otherwise 'no'")

state["is_valid_answer"] = (result.binary_score.lower() == "yes")

An answer can be factually grounded but still not answer the question. This catches that case.

The Full Graph

START → init_groq_model → prepare_vector_database
      → fetch_relevant_docs → filter_docs_by_relevance
      → [no docs → END] or [docs → produce_answer]
      → detect_hallucination → validate_answer → END

Self-RAG turns a one-shot pipeline into a self-auditing system. Every stage is a deliberate gate.

Built with LangGraph · LangChain · Groq · Chroma · HuggingFace · Python
